Airtightness products

An airtight home is comfortable and safe to live in. It is also energy efficient and sustainable. Ekovilla has always directed the construction industry towards airtight building and has developed products suitable for this purpose. An Ekovilla air barrier product with the marking X helps you build an airtight home. The X is a sign of airtightness.

Ekovilla X5 air barrier

Ekovilla X5 is a fabric-reinforced air barrier paper for breathable structures. It is used as an internal air barrier, especially with hygroscopic insulations such as cellulose.

Ekovilla X5 air barrier makes easy to build completely airtight buildings ensuring good indoor air quality and energy efficiency.

Ekovilla X 5 ilmansulku
  • Ekovilla X5 product information

    Ekovilla X5 product information

    • Width 130 cm
    • Length 46.2 m
    • Thickness 0.3 mm
    • Weight 161 g/m2
    • Water vapor permeability Sd 0,7 m
    • Tensile strength, longitudinal 523 N / 50 mm
    • Tensile strength, lateral 233 N / 50 mm
    • Longitudinal elongation 2.1%
    • Lateral elongation 5.7%

    Properties of Ekovilla X5 air barrier sheet

    • allows for a breathable structure ⇒ keeping the indoor air conditions closer to optimum level around the year
    • does not prevent the movement of moisture ⇒ capable of drying in both directions
    • meets the requirements for air barrier products 5:1 ⇒ reliable structure
    • flexible structure ⇒ easy to install in corners
    • fabric prevents the rivet from sinking ⇒ construction remains airtight

    Installation

    Ekovilla X5 is quick and easy to install. It withstands handling without tearing and can be installed even to difficult locations owing to its fabric reinforcement.

    The air barrier is fixed by stapling at 200 mm intervals. The joints are overlapped 200 mm or according to construction guidelines and joint durability is ensured by Ekovilla X Sealing tape.

Ekovilla X Reno

Ekovilla X Reno air barrier sheet is intended for use in traditional buildings and summer cottages. It is only suitable for use in hygroscopic insulation.

Ekovilla X Reno
  • Ekovilla X Reno product information
    • Width 130 cm
    • Length 46.2 m
    • Thickness 0.2 mm
    • Weight 170 g/m2
    • Water vapor permeability 0.05 Sd (EN 13984:2005)
    • Tensile strength, longitudinal 779 N / 50 mm
    • Tensile strength, lateral 276 N / 50 mm
    • Longitudinal elongation 2.0%
    • Lateral elongation 5.0%

Ekovilla Smart X vapour barrier membrane

Ekovilla Smart X is a vapour barrier membrane with variable diffusion resistance. Moisture variability increases the drying potential of the structure compared to traditional vapour barriers. It is compatible with all types of fibrous insulation materials.

  • Ekovilla Smart X product information

    Ekovilla Smart X product information

    • Weight 80 g/m2
    • Water vapour permeability Sd 17 m
    • Variable water vapour permeability Sd 0,4-45 m
    • Water permeability W1
    • Reaction to fire E
    • Tearing resistance (length/width) 80/90 N
    • Tensile strength (length/width) 120/120 N/50mm
    • Elongation (length/width) 80/90 %

    Properties of Ekovilla Smart X

    • suitable for all insulation materials ⇒ cellulose, wood fiber, mineral wool
    • open for diffusion in summer ⇒ improves the structure’s drying ability compared to traditional vapor barriers
    • transparent and light material ⇒ easy to attach to timber frame
    • flexible and durable ⇒ easy to install even in corners

    Installation

    Ekovilla Smart X is quick and easy to install. It withstands handling without tearing and can be installed even to difficult locations owing to its flexibility. Furthermore, the transparency of the fabric facilitates attachment to timber frame elements.
    The membrane is fixed by stapling at 200 mm intervals. The joints are overlapped 200 mm and joint durability is ensured by Ekovilla X Sealing tape.

    Download the product card

Ekovilla X sealing tape

Quality PE tape from the Ekovilla X range, with strong adhesive and mesh reinforcement. Suitable for taping the air barrier sheets Ekovilla X5 and Ekovilla X Reno.

Ekovilla X feed-through seal

The Ekovilla X feed-through seal is intended especially for sealing the feed-throughs of ventilation pipes, central vacuum cleaner pipes and electric pipes. The feed-through element has a self-adhesive flange. Thanks to its size the flange part seals even the largest perforations and cuts you need to make for installing ventilation pipes etc.

Ekovilla X läpivienti
  • Ekovilla X feed-through seal product information

    Ekovilla X feed-through seal product information

    • Flange section size 295 x 295 mm
    • Suitable for pipes 5–160 mm
    • Made of PE plastic
    • Pressure-sensitive adhesive
    • Installation temperature > +5 °C
    • Recyclable material

    Properties of Ekovilla X feed-through seal

    The flange collar is flexible and forms tightly around the pipe. Installing the Ekovilla X feed-through seal is quick and easy.

    Installation drawings for the feed-through seal

    1. Cut a hole slightly smaller than the pipe diameter.
    2. Clean around the pipe and remove the back papers.
    3. Press the feed-through seal firmly into place.
    4. Ensure airtightness of edges and pipe by using Ekovilla X sealing tape.
